HOWO 6×4 400HP

Drive Type	6x4 / 10 Wheels / 3 Axles
Horsepower	400 HP
Transmission	HW19710, 10F & 2R
Cargo Body Volume	16CBM / 18CBM / 20CBM

GET A QUOTATION

Why Buy From Us

Top Quality, Fair Price.
High Power, Smart Technology.
Built to Last, Made to Perform.

MORE INFORMATION

Ask for more information about this truck on WhatsApp

Additional information

Truck Type	Tipper \| Dump Truck
Brand	Sinotruk
Horsepower	400 HP
Wheel Configuration	6×4
Tonnage	30 Ton
Body Volume	20 m³
Drive Type	6×4 / 10 Wheels / 3 Axles
Suspension	Leaf Spring
Cabin Type	adjustable steering wheel, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, with four piont support floating suspension+shock absorbe, with one sleeper and two seats, double arm windscreen wiper system with three speeds
Transmission	HW19710, 10F & 2R, with PTO Ratio:14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Chassis Model	ZZ3257V3847B1
Engine	6-cylinder in-line with water cooling, turbo-charging and intercooling, Diesel 4-stroke direct injection diesel engine, Displacement: 9.726 L, Engine model: WP10.380E22, Euro 2, 380 HP, Make: Weichai
Front Axle	VGD95,1×9500 KGS Steering with doubleT-cross section beam
Rear Axle	HC16, 2×16000 KGS Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles. Ratio:5.73
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Chassis	Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members
Brake System	Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake
Electrics	Alternator: 3-phase, 28 V, 1500 W, Batteries: 2 x 12 V, 165 Ah, Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light, Operating voltage: 24 V, negative grounded, Starter: 24 V, 5.4 Kw
Tyres	12.00R20, radial tyres with one spare tyre
Fuel Tank	300L
Cargo Body	580023001500 mm, 20 CBM, Floor 8mm Side 6mm
Overall Dimension	875025503450mm
Cargo Body Volume	16CBM / 18CBM / 20CBM
